Additional Information
Jack Load
impedance
Jack Load
impedance Output
impedance Type Rated
output level
Rated
output
level
a)
Output
impedance Type
Jack Type Input
impedance Rated input
level
a)
ANALOG
(LINE) Phono-plug
jack 47 kilohms –12 dBs
Jack Type Input
impedance Rated input level
COAXIAL Phono-plug
jack
75 ohms 0.5 Vp-p
OPTICAL Optical jack — —
ANALOG
(LINE) Phono-plug
jack 470 ohms –12 dBs 47 kilohms
PHONES Stereo phone-
plug jack
100 ohms 0.36 mW 32 ohms
COAXIAL Phono-
plug jack
75 ohms 0.5 Vp-p 75 ohms
OPTICAL Optical
jack
— Wavelength:
660 nm —
Input jacks
Analog Input
Output jacks
Analog Output
Digital Output
Audio characteristics
Frequency response b) Standard: 20-20,000 Hz (±0.5 dB)
Long-play: 20-14,500 Hz (±0.5 dB)
Signal-to-noise ratio b) 90 dB or more (20 kHz LPF, A-Weight
filter ON)
Total harmonic distortion b)
Standard: 0.05% or less
Long-play: 0.3% or less
(1 kHz, Reference level
a) 20 kHz LPF
ON)
Wow and flutter Below measurable limit (±0.001%
W.PEAK)
a) The reference level corresponds to –20 dB on the peak level
meters.
b) During analog input with the SBM function off
Supplied accessories See page 4.
