B.5 IR Connector (CN8) Reserved
B.6 LVDS Connector (CN4)
Pin
Signal
1
+5V
2
X
3
IR_RX
4
GND
5
IR_TX
Pin
Signal
Pin
Signal
1
GND
2
GND
* VDDSAFE can
choose +5V or +12V
output via JP2
3
LVDS_NO
4
N/A
5
LVDS_P0
6
N/A
7
LVDS_N1
8
GND
9
LVDS_P1
10
N/A
11
LVDS_N2
12
GND
13
LVDS_P2
14
N/A
15
LVDS_CN1
16
GND
17
LVDS_CP1
18
N/A
19
VDDSAFE *
20
VDDSAFE *
1
2
4
3
5
19
2
1
20
17
18
4
3
