Advantech Vechicle Mounted Terminal PPC-V106 User Manual
Page 31
CHAP
T
ER
4
Jumper Settings and
Connectors
This chapter tells how to set up the
panel PC hardware, including instruc-
tions on setting jumpers and connecting
peripherals, switches and indicators. Be
sure to read all the safety precautions
before you begin the installation proce-
dures.
Sections include:
• Setting Jumpers
• CPU Installation
• CMOS Clear for External RTC (JP1)
• COM-port Interface
• VGA Interface
