PPC-V106 User Manual 22
4.1.3 Connectors
Onboard connectors link the panel PC to external devices such as hard
disk drives or floppy drives. The table below lists the function of each of
the board ís connectors.
Table 4.2: Panel PC connectors
Label Function
CN1 Power input connector
CN2 Flat panel display connector (Reserved)
CN4 LVDS connector
CN8 SIR connector (Reserved)
CN10 Inverter power connector
CN11 Print port connector
CN12 Line/Mic in connector (Reserved)
CN13 Line out connector
CN14 Internal Speaker connector (Reserved)
CN15 2.5 " IDE connector
CN16 Floppy drive connector (Reserved)
CN17 CFC connector
CN18 Slim type CD-ROM/IDE connector
CN20 USB 3
CN21 USB 4
CN23 COM4 connector
CN24 Mini PCI socket
CN26 COM 3 connector
CN27 Front panel connector
