Voice memo – Nikon L620 User Manual
Page 152

E
54
Re
fe
re
nce
S
ect
ion
Voice Memo
Voice memos can be recorded and attached to images.
Recording Voice Memos
• Press and hold the k button to record (up to about 20
seconds).
• Do not touch the microphone.
• During recording, o and p flash in the monitor.
• The voice memo playback screen is displayed after
recording ends. Press the
k button to play back the voice
memo.
• Delete the current voice memo before recording a new
voice memo (
• p is displayed for images with a voice memo when in full-frame playback mode.
Playing Voice Memos
Select an image with p displayed before pressing the
d
button.
• Press the k button to play the voice memo. Press the
button again to stop playback.
• Move the zoom control during playback to adjust playback
volume.
Press the c button (playback mode) M select an image M d button M
Voice memo M k button
1 7 s
1 7 s
Back
Back
2 0 s
2 0 s
