- 7 -
1.2 Operating Environment
Leave extra space around and above the unit to ensure smooth
operation. Please refer to the drawing at right for the amount
of space to be provided.
If possible, place a suitable cover over the unit to avoid dust
accumulating when it is stored.
The necessary space when the Auto Slide Feeder SF-100 is
attached is shown below.
➤
➤
2˝
(5cm)
➤
➤
2˝
(5cm)
6inches
(15cm)
➤
➤
➤ ➤ 4inches
(10cm)
23.6˝
(60cm)
➤
➤
