- 12 -

4.2

Setting Mounted Slides

Set the slides to be read by LS-1000 in the insertion side of the
magazine.

Step 1

Open the magazine cover.

Step 2

Next, grip the slide push plate in the insertion side with your
fingers, pull it back against the spring, and catch it in the notch
so that it cannot return to its original position.

Note: Make sure that the slides are inserted with the emulsion
surface (rough surface) toward the slide push plate.

Ejection Magazine

Insertion Magazine

Magazine
Cover

Insert Guide
Stickers
