- 13 -

Note: Make sure that the slides are inserted with the longer sides
of the film at the top and bottom. Inserting the slide with the
shorter sides at the top and bottom may result in damage to the
film or mount.

Note: Insert Guide Stickers shown below help you to insert slides
correctly.

Insert Guide Stickers

Magazine side

Place the slides in the insertion side of the magazine.

Slides can be placed in the insertion side of the magazine up to
the reference mark.

✔

Remarks

Do not insert slides beyond the reference mark, as this may
cause them to jam.

Reference Marks

The slide push plate should be set to the locking position where
the notch is given.
