- 18 -
Appendix: Specifications
Film used: 35mm mounted slides of 1.1 - 3.0mm in
thickness
Maximum number of slides:
About 50 1.6mm thick mounted slides
(Magazine space: approx. 80mm)
Connection: Directly connected to front panel connector
of vertically installed LS-1000.
Reference insertion/ejection time:
Insertion: approx. 10 seconds
Ejection: approx. 10 seconds
Power source: Supplied by LS-1000. DC 12V 350mA or
lower, DC 5V 30mA or lower.
Size: 5.1(W) x 7.8(D) x 6.2(H) inches
(130 x 199 x 156.5mm)
Weight: Approx. 1.8 lbs (0.8kg)
Index
A
accessories 8
D
display LED 9
E
ejection Magazine 9
I
insertion magazine 9
J
jams, clearing 17
M
magazine cover 9
mounting the SF-100 on the LS-1000 10
O
operating environment 7
P
power source 18
R
removing mounted slides 15
removing the auto slide feeder 16
S
setting mounted slides 12
specifications 18
