AT-MC1004 and AT-MC1005/x Series Installation Guide
19
RJ-45 Pin Assignments
Figure 8 shows the pin assignments of the media converter’s RJ-45 port.
Figure 8 RJ-45 Pin Assignments
Table 7 lists the RJ-45 connector pins and their signals for 1000Base-T.
Table 7 RJ-45 Connector Pinouts
Pinout
Pair
Signal
1
0
TX and RX+
2
0
TX and RX-
3
1
TX and RX+
4
2
TX and RX+
5
2
TX and RX-
6
1
TX and RX-
7
3
TX and RX+
8
3
TX and RX-
Pin 1
Pin 8
