Installing the Media Converter
10
Table 3 Twisted Pair Cabling Specifications
Note
The 1000Base-T ports use 4 pair (8 wires) in a twisted pair cable.
Table 4 Fiber Optic Cabling Specifications
Selecting a Site
Be sure to observe the following requirements when choosing a site for your
media converter.
❑
Select a site that is dust-free and moisture-free.
❑
Be sure that the site will allow you to easily access the fiber optic and
twisted pair cables and the power cord.
❑
Use dedicated power circuits or power conditioners to supply reliable
power to the device.
Model Cable Maximum Operating
Distance
All Models Shielded Twisted Pair Category 5
or better 100 m (328 ft)
Model Cable Maximum
Operating
Distance Maximum
Allowable Loss
Budget
AT-MC1004 50/125 micron multimode 550 m (1,804 ft) 8.5 dB at 850 nm
62.5/125 micron
multimode
1
1. Based on the multi-mode fiber cable with 200MHz per kilometer on the modal bandwidth @ 850 nm.
275 m (902 ft) 7.5 dB at 850 nm
AT-MC1005/1 9/125 micron single-mode 10 km (6.2 mi) 17.0 dB at 1310 nm
AT-MC1005/2 9/125 micron single-mode 20 km (12.4 mi) 18.0 dB at 1310 nm
AT-MC1005/3 9/125 micron single-mode 2
2. For maximum performance of Gigabit Optical Datalinks when greater than 40 km (24.8 mi) and operating within the
1550 nm optical spectrum, it is mandatory that the Single-mode Fiber (SMF) be rated as non-dispersion-shifted,
dispersion shifted, or non-zero dispersion shifted.
40 km (24.8 mi) 18.0 dB at 1550 nm
AT-MC1005/4 9/125 micron single-mode 2 70 km (43.4 mi) 20.0 dB at 1550 nm
