A R 3 0 0 R O U T E R Q U I C K S T A R T G U I D E 27
Example output from the SHOW PBX GROUP command.
Example output from the SHOW PBX EXTENSION command.
Extension: 0
Type ...................... user configured
Name ...................... Foyer
Port ...................... 0
Suppress .................. 0
Auto terminate ............ 0
Group ..................... default
Divert .................... none
Number .................... not set
Rebound ................... 20
Accept number ............. off
Accept subaddress ......... off
Calling Number ............ off
Transfer .................. 20
Bearer Cap ................ speech
Autodial .................. none
HLC ....................... default
No HLC .................... accept
Bar Number(s):
external 9
Override Number(s): Priority
external 9 000 high
Extension: 1
Type ...................... user configured
Name ...................... Bill Hodge
Port ...................... 1
Suppress .................. 0
Auto terminate ............ 0
Group ..................... sales
Divert .................... none
Number .................... not set
Rebound ................... 20
Accept number ............. off
Accept subaddress ......... off
Calling Number ............ off
Transfer .................. 20
Bearer Cap ................ speech
Autodial .................. none
HLC ....................... default
No HLC .................... accept
.
.
.
Group: default
Extension ................. 0
Accept number ............. off
Accept subaddress ......... all
Hunt ...................... search
Transfer .................. 20
Extension List ............ 3 0
Group: sales
Extension ................. 1
Accept number ............. 2
Accept subaddress ......... all
Hunt ...................... search
Transfer .................. 20
Extension List ............ 2 1
0 again and dial 0 (the operator prefix), a call should be made
to extension 1 and that telephone should ring.
2 Pick up extension 1 and dial 9; the network dial tone should
be heard. Check that a call can be made to an external number.
Make a call to Head Office by dialling the shortcode 20. Dial
the facsimile machine’s extension and check that the facsimile
machine answers.
3 From the facsimile machine call the directory number
assigned to the sales group and check that first one extension
rings then the other. The order they ring in is determined by
the order in which the extensions were added to the group.
Save the Configuration
Save the router configuration by entering the command:
CREATE CONFIG=BOOT.CFG
where boot.cfg is the name of the current router configuration.
TROUBLESHOOTING PBX CONFIGURATIONS
1 Check the configuration of the PBX module, its extensions
and its groups with the commands:
SHOW PBX
SHOW PBX EXTENSION
SHOW PBX GROUP
2 The calls currently in progress and their state can be
displayed with the command:
SHOW PBX CALL
