Chapter 1, Overview – Allied Telesis AT-FS705LE User Manual
Page 13
1
Chapter 1
Overview
The AT-FS705LE Fast Ethernet Switch is a
10Base-T/100Base-TX unmanaged switch. The
switch provides you with a simple, cost-effective
solution for Ethernet switching between end-
nodes operating at either 10 Mbps or 100 Mbps.
Figure 1 and Figure 2 show the front and back
panels of the switch.
Figure 1 AT-FS705LE Front Panel
DC Power Connector
Port LEDs
DC Polarity
Symbols
