Chapter 5: VLANs
44
3. In the VID field, supply a number for the VLAN ID, from 2 to 4094.
4. In the VLAN Name field, enter a unique name for the VLAN. No
spaces are allowed.
5. In the Tag row, select the ports that you want to be tagged members of
the VLAN.
Note
If you want a port to be an untagged member of a different VLAN,
you must first modify the VLAN (usually the default VLAN) where the
port is an untagged member. First, delete that port from the original
VLAN and then assign the port to another VLAN as an untagged
port.
6. To select the ports you want to assign to the VLAN, do one of the
following:
ˆ In the None row, click the port that you do not want to be included
in the VLAN.
ˆ In the VLAN Member row, select the ports that you want to assign
to the VLAN.
7. Click Apply to implement your changes.
8. To save the settings to the configuration file, from the main menu,
select Save Configuration.
The Save Configuration page is shown in Figure 3 on page 14.
9. Click Apply.
Displaying all
VLANs
To view all the currently configured VLANs, perform the following
procedure:
1. From the main menu, select VLAN Configuration.
The VLAN Configuration page is shown in Figure 15 on page 43.
2. Click Show All Static VLAN Entries.
