AT-FS717FC/SC Fast Ethernet Switch Installation Guide
13
The AT-FS717FC/SC switch can be used on a desktop or mounted on a
wall. The switch is easy to install and does not require software
configuration or management.
Key Features
The AT-FS717FC/SC switch has the following key features:
ˆ 10/100 Mbps (10Base-T / 100Base-TX) twisted pair ports
with RJ-45 connectors
ˆ 100 Mbps (100Base-FX) fiber optic port with SC connector
ˆ System and port LEDs
ˆ Duplex mode switch (for fiber optic port)
ˆ Support half- or full-duplex mode on all ports
ˆ Auto MDI/MDI-X on all 10/100 Mbps twisted pair ports
ˆ Auto-Negotiation (IEEE 802.3u-compliant)
ˆ Flow control (IEEE 802.3x-compliant)
ˆ Store-and-forward packet forwarding
ˆ Storage up to 4K MAC addresses
ˆ For use on a desktop, in a rack, or on a wall
ˆ RoHS Compliant
Standards
ˆ IEEE 802.3 – Ethernet
ˆ IEEE 802.3i – 10Base-T
ˆ IEEE 802.3u – 100Base-TX
ˆ IEEE 802.3x – Flow Control, Symmetric and Asymmetric
