AT-FS20x Series Installation Guide
19
AT-FS202 50/125 or
62.5/125
micron
multimode 2 km
(1.24 mi) 9.3dB @ 1310nm
(50/125 MMF)
12.8dB @ 1310nm
(62.5/125 MMF)
AT-FS202SC/FS1 9/125 micron 2
single-mode
15 km
(9.4 mi) 16dB at 1310nm
1. Maximum distance for 100 Mbps optical datalinks is dependent on the follow-
ing factors: quality of fiber optic, duplex mode of both end-nodes, and maxi-
mum optical loss budget for the optical fiber at each operating optical
wavelength.
2. The fiber optic strand can be non-dispersion-shifted, or non-zero dispersion-
shifted single-mode cable.
Table 4. 100Base-FX Fiber Optic Cabling Specifications (Full-duplex)
Model Cable Type
Maximum
Operating
Distance
1
Maximum
Allowable Loss
Budget
