17
Chapter 2
Installation
This chapter explains how to install the AT-FS201, AT-FS202, and
AT-FS202SC/FS1 Bridging Media Converters. These converters can be
installed on a desktop, in an AT-WLMT-010 wallmounting bracket, or in an
AT-MCR12 chassis.
Verifying Package Contents
Make sure the following items are included in your package. If any item is
missing or damaged, contact your Allied Telesyn sales representative for
assistance.
ˆ One AT-FS201, AT-FS202, or AT-FS202SC/FS1 Bridging Media
Converter
ˆ Four protective feet (for desktop use only)
ˆ External AC/DC power supply (12VDC model only)
ˆ This installation guide
ˆ Warranty card
Note
For information on the power supplies used with the AT-FS201,
AT-FS202, and AT-FS202SC/FS1 Bridging Media Converters,
refer to “External Power Supply” on page 6.
