Chapter 1: Overview
4
Bridging Media Converter Components
Figure 4 shows the front panel of the AT-FS201 Bridging Media
Converter.
Figure 4. AT-FS201 Front Panel
Figure 5 shows the front panel of the AT-FS202 Bridging Media
Converter.
Figure 5. AT-FS202 Front Panel
Figure 6 shows a front panel of an AT-FS202SC/FS1 Bridging Media
Converter.
Figure 6. AT-FS202SC/FS1 Front Panel
