Chapter 1: Overview
28
PoE Network
Topology
In the topology shown in Figure 4, an AT-GS900/8POE Gigabit Ethernet
switch is connected to an AT-9424T/SP Gigabit Ethernet Switch and a
number of POE powered devices in different locations.
Figure 4. PoE Network Topology
