AlliedView™-EMS 3.11 VLAN Manager User’s Guide Page 68 of 72
6.16.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field Valid Values Length
Name (cannot be
modified)
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
Note - VLAN names must contain at least one (1)
alphabet character.
Note - "ALL" is a reserved word and cannot be
used as a VLAN name.
1 - 32
characters
Identifier (cannot be
modified)
1 - 4094 -
Operation Mode (cannot
be modified)
• Normal
• Private
• Nested
-
6.16.3 Notes
• When adding/modifying a Nested VLAN, specifying a port that is already a
member of an existing Normal VLAN will not generate any error. However, the
specified port will be ignored. In addition, during modification, existing member
ports having the same status (tagged/untagged) as the specified port will be
deleted.
• When importing the default VLAN, VLAN Manager disregards the values
specified for Untagged Ports.
During an Import VLAN operation, VLAN Manager will ignore the values
specified for certain fields depending on the value specified for the Operation
Mode field:
- If Operation Mode is "Normal" - Uplink Port, Private Ports, Core Ports and
Customer Ports
- If Operation Mode is "Private" - Core Ports and Customer Ports
- If Operation Mode is "Nested" - Tagged Ports, Untagged Ports, Uplink Port
and Private Ports
• User-created VLANs are classified as Multiple Type VLANs. There are three
possible VLAN associations for a Multiple Type VLAN: IP Subnet, Protocol and
Port. Currently, VLAN Manager only supports Port association. As a result,
when attempting to modify a VLAN with an association other than Port, VLAN
Manager automatically changes the association of that VLAN to Port.
