AlliedView™-EMS 3.11 VLAN Manager User’s Guide Page 55 of 72
6.11.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field Valid Values Length
Name (cannot be
modified)
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
Note - VLAN names must contain at least one (1)
alphabet character.
Note - "ALL" is a reserved word and cannot be used as
a VLAN name.
AT-8900:
1 - 15 characters
If the software
release version is
2.7.3 or higher:
1 - 32 characters
AT-9900/AT-
x900-48:
1 - 32 characters
Identifier (cannot
be modified)
1 - 4094 -
Operation Mode
(cannot be
modified)
- Normal
- Private
- Nested
-
6.11.3 Notes
• AT-x900-48FS: The current firmware version does not allow VLAN Manager to
display the correct image for SFP Module ‘AT-SPFXBD-LC-13’. As a result, the SFP
image that will be displayed is the generic SFP Fiber image.
• When adding/modifying a Nested VLAN, specifying a port that is already a member
of an existing Normal VLAN will not generate any error. However, the specified
port will be ignored. In addition, during modification, existing member ports having
the same status (tagged/untagged) as the specified port will be deleted.
• When importing the default VLAN, VLAN Manager disregards the values specified
for Untagged Ports.
• During an Import VLAN operation, VLAN Manager will ignore the values specified
for certain fields depending on the value specified for the Operation Mode field:
o
If Operation Mode is "Normal" - Uplink Port, Private Ports, Core Ports and
Customer Ports
o
If Operation Mode is "Private" - Core Ports and Customer Ports
o
If Operation Mode is "Nested" - Tagged Ports, Untagged Ports, Uplink Port
and Private Ports
• User-created VLANs are classified as Multiple Type VLANs. There are three
possible VLAN associations for a Multiple Type VLAN: IP Subnet, Protocol and Port.
