AlliedView™-EMS 3.11 VLAN Manager User’s Guide Page 51 of 72
Input Field Valid Values Length
Operation Mode
(cannot be
modified)
- Normal
- Private
- Protected
-
6.9.3 Notes
• When importing the default VLAN, VLAN Manager disregards the values specified
for Untagged Ports.
• During an Import VLAN operation, VLAN Manager will ignore the values specified
for the Uplink Port and Private Ports fields if the value specified for the Operation
Mode field is "Normal" or "Protected".
• When two Private VLANs specify the same Uplink port (Uplink port is untagged for
the first Private VLAN and tagged for the second Private VLAN), modifying the
Private VLAN that has the untagged Uplink port will result in the error message:
" already has an uplink, more than one Uplink is not permitted." All
ports in that Private VLAN will then be deleted.
6 Device Support
