AlliedView™-EMS 3.11 VLAN Manager User’s Guide Page 59 of 72
6.13 AT-9400 Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
• Notes
6.13.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Type
This indicates the type of the VLAN.
• Port-based
• Mac-based
Note - VLAN Type is only available to Layer 3 models
with firmware version of 3.1.0 or higher.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports
This is a list of the untagged member ports of the
VLAN.
Status
This indicates the status of the VLAN.
• idle
• operational
• under-construction
• not-operational
6.13.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field Valid Values Length
Name
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
Note - VLAN names must contain at least
1 - 20 characters
