AlliedView™-EMS 3.11 VLAN Manager User’s Guide Page 38 of 72
6.3 AT-8124XL (v2)
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
• Notes
6.3.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Status
This indicates the status of the VLAN.
• idle
• operational
• under-construction
• not-operational
6.3.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs display the following Input Fields:
Input Field Valid Values Length
Name
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
0 - 20 characters
Identifier 1 - 4094 -
6.3.3 Notes
• The current firmware version does not allow the Default VLAN to be modified. As a
result, all VLAN Manager operations involving the Default VLAN will fail.
6 Device Support
