AlliedView™-EMS 3.11 VLAN Manager User’s Guide Page 57 of 72
6.12 AT-9000/24 and AT-9410GB
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
• Notes
6.12.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports
This is a list of the tagged member ports of the
VLAN.
Untagged Ports
This is a list of the untagged member ports of the
VLAN.
Status
This indicates the status of the VLAN.
• idle
• operational
• under-construction
• not-operational
6.12.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs display the following Input Fields:
Input Field Valid Values Length
Name
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
0 - 32
characters
Identifier 1 - 4094 -
