AlliedView™-EMS 3.11 VLAN Manager User’s Guide Page 39 of 72
6.4 AT-8200XL Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
• Notes
6.4.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Member Ports This is a list of the member ports of the VLAN.
Untagged Ports
This is a list of the untagged (port-based) member ports of the
VLAN.
Status
This indicates the status of the VLAN.
• idle
• operational
• under-construction
• not-operational
6.4.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs display the following Input Fields:
Input Field Valid Values Length
Name
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
0 - 20 characters
Identifier 1 - 4094 -
6.4.3 Notes
• Attempting to modify the Default VLAN will result in the error message "An error
occurred during the operation. Error: Bad Value."
