Chapter 2 hardware description – Allied Telesis AT-IFS802SP User Manual
Page 14
10
AT-IFS802SP-80 User Manual
Chapter 2 Hardware Description
In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling information, and wiring
installation.
2.1 Physical Dimension
8 10/100TX + 2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial Switch dimension (W
x D x H) are
72mm x 105mm x 152mm.
2.2 Front Panel
The Front Panel of the 8 10/100TX + 2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial
Switch is shown as below:
Front Panel of the industrial switch
