8 AT-IFS802SP-80 User Manual
1.2 Software Features
Management SNMP v1 v2c, v3/ Web/Telnet/CLI/NS-View
SNMP MIB
RFC 1215 Trap, RFC1213 MIBII, RFC 1157 SNMP MIB, RFC 1493 Bridge MIB,
RFC 2674 VLAN MIB, RFC 1643 , RFC 1757, RSTP MIB, Private MIB, LLDP MIB
VLAN
Port Based VLAN
IEEE 802.1Q Tag VLAN (256 entries)/ VLAN ID (Up to 4K, VLAN ID can be
assigned from 1 to 4096.)
GVRP (256 Groups)
Port Trunk with
LACP
LACP Port Trunk: 4 Trunk groups/Maximum 4 trunk members
LLDP
Supports LLDP allowing switch to advertise its identification and capability on
the LAN
Spanning tree
IEEE802.1d spanning tree
IEEE802.1w rapid spanning tree.
X-Ring
Supports X-ring, Dual Homing and Couple Ring Topology Provides redundant
backup feature and the recovery time below 20ms
Class of Service Supports IEEE802.1p class of service, per port provides 4 priority queues
Port Security
Supports 100 entries of MAC address for static MAC and another 100 for MAC
filter
Port Mirror Supports 3 mirroring types: “RX, TX and Both packet”.
IGMP Supports IGMP snooping v1,v2, 256 multicast groups and IGMP query
IP Security
Supports 10 IP addresses that have permission to access the switch management
and to prevent unauthorized intruder.
Login Security Supports IEEE802.1X Authentication/RADIUS
Bandwidth
Control
Supports ingress packet filter and egress packet limit
The egress rate control supports all of packet type and the limit rates are
100K~250Mbps
Ingress filter packet type combination rules are Broadcast/Multicast/Unknown
Unicast packet, Broadcast/Multicast packet, Broadcast packet only and all of
packet. The packet filter rate can be set from 100k to 250Mbps
Flow Control Supports Flow Control for Full-duplex and Back Pressure for Half-duplex
System Log Supports System log record and remote system log server
SMTP Supports SMTP Server and 6 e-mail accounts for receiving event alert
