6 AT-IFS802SP-80 User Manual
Chapter 1 Introduction
The 8 10/100TX + 2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial Switch is a cost-effective
solution and meets the high reliability requirements demanded by industrial applications. The 8 10/100TX +
2 10/100/1000T/SFP Combo with X-Ring L2 Managed Industrial Switch can be easily managed through the
Web GUI. Using fiber port can extend the connection distance that increases the network elasticity and
performance. It also provides the X-Ring function that can prevent the network connection failure.
1.1 Hardware Features
Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX
IEEE802.3ab 1000Base-T
IEEE802.3z Gigabit fiber
IEEE802.3x Flow Control and Back Pressure
IEEE802.3ad Port trunk with LACP
IEEE802.1d Spanning Tree/ IEEE802.1w Rapid Spanning Tree
IEEE802.1p Class of Service
IEEE802.1Q VLAN Tag
IEEE 802.1x User Authentication (Radius)
IEEE802.1ab LLDP
Switch
Architecture Back-plane (Switching Fabric): 5.6Gbps
Packet throughput ability(Full-Duplex): 8.3Mpps @64bytes
Transfer Rate
14,880pps for Ethernet port
148,800pps for Fast Ethernet port
1,488,000pps for Gigabit Fiber Ethernet port
Packet Buffer 1Mbits
MAC Address 8K MAC address table
Flash ROM 4Mbytes
DRAM 32Mbytes
Connector
10/100TX: 8 x RJ-45
10/100/1000T/ SFP Combo: 2 x RJ-45 + 2 x
100/1000 SFP sockets
RS-232 connector: RJ-45 type
