AT-2900 Series Gigabit Ethernet Network Adapters Installation Guide
113
Testing Network Connectivity
The following section describes how to test network connectivity for
Windows Server 2003, NetWare, and Linux networks.
Note
When using forced link speeds, make sure that both the adapter and
the switch are forced to the same speed. Or, make sure at least one
link partner is configured for Auto-Negotiation.
Windows Server
2003
To test the network connectivity for the Windows Server 2003 driver
software, perform the following procedure.
Use the ping command to determine if network connectivity is working.
1. Select Run from the Windows Control Panel
The Run command window opens, as shown in Figure 22.
Figure 22. Run Command Window
2. Type cmd and click OK.
3. Type ipconfig /all.
The command window opens, as shown in Figure 23 on page 114.
