Rj-45 1000base-t connector pinouts – Allied Telesis AT-GS924M User Manual
Page 54
Appendix A: Technical Specifications
54
Table 16 lists the RJ-45 connector pins and their signals when a
1000Base-T port is operating at 1000 Mbps.
Table 16. RJ-45 1000Base-T Connector Pinouts
Pin
Pair
Signal
1
1
TX and RX+
2
1
TX and RX-
3
2
TX and RX+
4
3
TX and RX+
5
3
TX and RX-
6
2
TX and RX-
7
4
TX and RX+
8
4
TX and RX-
