51
Appendix A
Technical Specifications
This appendix contains the following specifications:
 “Physical Specifications”
 “Environmental Specifications” on page 52
 “Power Specifications” on page 52
 “Safety and Electromagnetic Emissions Certifications” on page 52
 “Connectors and Port Pinouts” on page 53
Physical Specifications
Dimensions
Weight
Table 9. Chassis Dimensions
Model W x D x H mm (in)
AT-GS908M 263 mm x 179 mm x 38 mm
(10.35 in x 7.0 in x 1.5 in)
AT-GS916M 341 mm x 210 mm x 44 mm
(13.4 in x 8.3 in x 1.7 in)
AT-GS924M 440 mm x 210 mm x 44 mm
(17.32 in x 8.3 in x 1.7 in)
Table 10. Chassis Weight
Model kg (lbs)
AT-GS908M 1.4 kg (3.09 lbs)
AT-GS916M 2.0 kg (4.41 lbs)
AT-GS924M 2.7 kg (5.95 lbs)
