AT-GS908M, AT-GS916M, and AT-GS924M Switches Installation Guide
21
Twisted-Pair Ports
The AT-GS908M, AT-GS916M, and AT-GS924M Layer 2 Gigabit Ethernet
Switches feature 8, 16, and 24 twisted-pair ports, respectively. All ports
are 10Base-T, 100Base-TX, and 1000Base-TX compliant. You can set the
port speeds and duplex modes either automatically with IEEE 802.3u
Auto-Negotiation or manually with the management software.
The twisted-pair ports feature 8-pin RJ-45 connectors. For the port
pinouts, see “Connectors and Port Pinouts” on page 53.
The ports have a maximum operating distance of 100 m (328 feet). For 10
Mbps operation, the ports require Category 3 or better 100 ohm shielded
or unshielded twisted-pair cabling. For 100 or 1000 Mbps operation, the
ports require Category 5 or Enhanced Category 5 (5E) 100 ohm shielded
or unshielded twisted-pair cabling.
The ports feature auto-MDI, which automatically configures the ports as
MDI or MDI-X. This feature allows you to use straight-through twisted-pair
cables, regardless of the wiring configurations of the ports on the end
nodes.
Note
A switch port connected to an end node that is not using Auto-
Negotiation should not use Auto-Negotiation to set the speed and
duplex mode, because a duplex-mode mismatch may occur. In this
case, disable Auto-Negotiation and set the port’s speed and duplex
mode manually.
