43
Using MHL
Using MHL
MOBILE
1. Connect the Micro USB port on the mobile device to the MOBILE port on the product using
the mobile cable.
2. Connect the DC power adapter to the product and a power socket.
3. After the power is connected, the product will automatically detect and change the input
source.
• Press the [
] button and set Select Source to MHL .
• If the input source is not set to MHL , press the [ ] button to change the input
source.
NOTE
• Mobile devices should be purchased separately.
• MHL output resolution can vary by mobile device manufacturer. For this reason, the picture quality of
images displayed on the product may not be the same.
4. If the following message appears, MHL mode is activated. After about 3 seconds, the MHL
screen will be displayed.
HDMI / USB / Wireless Connection MHL
[MHL] 3 sec later
MHL activated.
MHL
• Wireless Connection is displayed on Series 7 only.
NOTE
The indicated time "after 3 seconds" may vary depending on the mobile device.
When the mobile device is in power-saving mode
NOTE
When the mobile device is in power-saving mode, the following message will appear in place of the MHL
screen. To display the MHL screen, deactivate power-saving mode.
MHL device is in sleep mode.
