23
Using Smart Station
Automatic installation when using a desktop
PC
1. After opening the package, connect the Smart Station monitor to your desktop PC using
the HDMI cable provided in the package.
HDMI OUT HDMI IN
2. Check that the output from the desktop PC is displayed on the monitor.
3. Connect the USB cable provided in the package to a USB port when the HDMI cable is
connected.
USB
HDMI IN HDMI OUT
4. After the connection is established between the Smart Station monitor and PC using the
USB cable, the following software programs required to use the Wireless Connection , USB
Hub, and Mobile Control functions will automatically install.
(Wireless Connection Manager (for Series 7 only), USB Display Driver, Ethernet
Driver, Mobile Control)
NOTE
• Do not remove the cable or turn off the product until install is complete.
• Even if the USB cable is connected, the PC screen will not be displayed on the monitor until the
install is complete.
5. Automatic installation may not be supported depending on your PC system settings.
If automatic installation does not work, run Windows Explorer. Open My Computer –
Removable media device drive and check the software. Finally, double-click the software to
proceed with installation. Alternatively, install using the software program on the provided
CD.
• Install using Explorer
A virtual installation driver will appear. Double-click the icon to install the program.
NOTE
• It may take a while for the virtual driver to appear.
• Do not remove the cable or turn off the product until install is complete.
