8
Identification of features
Bottom
Ú To open the battery chamber cover, slide it in the direction shown above.
Q Icon Status Description
Icon Status Description
Blinking
For 2 seconds, the lamp blinks quickly at 0.25-
second intervals before taking a picture.
Blinking
A picture will be taken after about 10 seconds and
2 seconds later a second picture will be taken.
Blinking
- For the first 8 seconds, the lamp blinks at 1
second intervals.
- For the final 2 seconds, the lamp blinks quickly at
0.25second intervals.
Blinking
Pressing the shutter button of remote control will
allow an interval of 2 seconds before the image
is taken.
Q Camera Status Lamp
Status Description
After taking a picture
The lamp blinks while saving the image and
then turns off when ready to take another
picture.
When the USB cable is
inserted to a PC The lamp lights up. (LCD monitor turns off after
initializing the device)
Transmitting Data with
a PC
The lamp turns on. (LCD monitor turns off)
When the USB cable is
disconnected to a printer
The lamp is off.
When the printer is printing The lamp blinks.
When the AF activates
The lamp lights. (The subject is in focus)
The lamp blinks. (The subject is not in focus)
Battery chamber cover
Battery chamber
Battery holder
Memory card slot
Battery cover lever
Tripod Socket
USB/AV Connection Terminal
