xii
Hardware setup 33
Turning on the server and running the Power-On
Self Test (POST)
34
Software setup 36
Network teaming features 37
3 Hardware configuration 39
Installation precautions 41
ESD precautions 41
Preinstallation instructions 42
Post-installation instructions 42
Tools and supplies needed 43
System access panels 44
Before removing the access panels 44
Rear access panel 44
Front access panel 45
Front subchassis and rear
electronics bay
47
Opening the front subchassis and rear
electronics bay
47
Removing the front subchassis and rear
electronics bay
48
Closing the front subchassis and rear
electronics bay
50
Accessing the system boards 51
Access cover to the system boards 51
Memory board 52
53
53
53
Processor board 54
Mainboard 55
Memory 60
DIMM sequence 60
Processors 63
Processor sequence 63
PCI add-in boards 67
PCI add-in board locations 67
Operating system support for hot-plug
add-in boards
68
Checking the status indicators for a hot-plug
add-in board
68
Installing and removing a hot-plug PCI
