Setting the Baud Rate
Baud rate is the number of bites transmitted per second in a serial data transmission system. If
you have our personal computer software and you want to control the display by your personal
computer, you have to check the baud rate of RS-232 port that built in your personal computer.
Baud rate of your personal computer must be as the same as The ArizonaSun.
To adjust the baud rate of the display:
[Procedures]
1. Press [Run/Stop] and then the [PROG] key to enter editing mode.
2. Press [GRAPH] key.
3. Press the [ESC] key and the display will read: Baud Rate – 9600.
4. Press the [
↑] or [↓] key to adjust the number. (There are four choices: 9600, 4800, 2400,
1200)
5. Press [Run/Stop] to let the resume the display animation.
