ARIZONA SUN
12
Each graphic is composed of 42 points; they are in a format of 7 rows and 6 columns. The [A] key
represents the first point of the first raw and also the first point of the first column. The [%] key
represents the 7
th point of the 7 th row and also the 7 th point of the 7 th column.
7. Press any key in the above chart once or twice to get the corresponding position’s LED lit
or extinguished. Continue this process to have your own graphic.
8. Press [SHIFT] and the [B] key simultaneously, the 2 nd graphic will flash and has become
editable.
9. Press [Run/Stop] key to resume the display animation.
Inserting graphics:
1. Press [Run/Stop] and then the [PROG] key to enter the editing mode.
2. Press [GRAPH] key.
3. Press [SHIFT] and the [B] key simultaneously. The second graphic that is stored in the
memory will appear.
4. Press [Alt] and then the [End] key.
5. Press [Run/Stop] to resume the display animation.
Note: See Sample Graphics (page. 15)
Erasing All Message
To erase all messages in The ArizonaSun:
[Procedures]
1. Press [Run/Stop] and then the [PROG] key to enter editing mode.
2. Press the [ESC] key.
3. Press the [DEL] key and the display will read: ALL CLEAR? Y/N.
4. Press the [Y] key will erase all messages from the display’s memory.
5. Press the [N] key will return to the editing mode.
Checking the Version Number
You can identify your display’s version by checking the serial number label with is located at
the reverse of the display. You can also check the version umber of the software in the display by
following the procedures:
[Procedures]
1. Press [Run/Stop] and [PROG] key to enter editing mode.
2. Press [SHIFT] key.
3. Press [PROG] key and the display will read VER 2.1 or VER 2.2 or any other version
numbers.
4. Press [Run/Stop] to resume display animation.
