CS125 Present Weather Sensor
8
mounted away from the sensor head to avoid wind flow disturbance or rain
drops bouncing back up into the sensor’s sensing volume.
Take care not to overtighten the nuts on the bolts, as it may
be possible to distort and/or damage the brackets or DSP
plate by doing so, and/or the nuts may seize up. Only tighten
the nuts to a degree necessary to hold the CS125 firmly in
place.
Where the CS125 is to be mounted onto another type of mast, please refer to
the manual for that mast for mounting details.
Ensure that the CS125 is mounted according to the figure
below. Do not reposition, once fixings are tightened, by
forcing the arms of the unit as this can cause damage.
Slots are provided to allow band clamps to be used with larger diameter masts.
CAUTION
CAUTION
