Appendix D. AL200 Settings
SE1 Transmitted Last three transmitted readings for SE1 (T0, T1, T2). The list will be queried and
displayed here at a regular refresh interval. While connected via Device
Configuration Utility, automated reporting/transmission is disabled. Press and hold
the test button for 3 to 5 seconds to force a transmission while connected.
C1 Raw Reading If C1 input is enabled, this will be either a) the control port state or b) the value for
SDI-12 without SDI-12 Multiplier and SDI-12 Offset applied, during the last sensor
scan. While connected via Device Configuration Utility, C1 will be measured every
Configuration Sensor Scan Interval. The measured value will be queried and
displayed here at a regular refresh interval.
C1 Scaled Reading If C1 input is enabled, this will be either a) the control port state or b) the value for
SDI-12 with SDI-12 Multiplier and SDI-12 Offset applied, during the last sensor
scan. While connected via Device Configuration Utility, C1 will be measured every
Configuration Sensor Scan Interval. The measured value will be queried and
displayed here at a regular refresh interval.
C1 Transmitted If C1 input is enabled, this will be either a) the control port state or b) the value for
SDI-12 for the last three transmitted readings of C1 (T0, T1, T2). The list will be
queried and displayed here at a regular refresh interval. While connected via Device
Configuration Utility, automated reporting/transmission is disabled. Press and hold
the test button for 3 to 5 seconds to force a transmission while connected.
D-4
