Appendix B. Cables and Connector Pin
Descriptions
B.1 CS I/O
CS I/O is an interface unique to Campbell Scientific products. CS I/O uses
TTL signaling. CS I/O devices are connected using a 9-pin, straight-through,
male to female cable with all 9 pins connected. Use of the supplied SC12 cable
(pn 16675) is recommended.
TABLE B-1. CS I/O Pin Description
Pin Datalogger Function, DB9 Female AL200 Function, DB9 Male
1
5 VDC
N/C
2
SIGNAL GND
SIGNAL GND
3
RING
RING
4
RXD
TXD
5
ME
ME
6
SDE
SDE
7
CLK/HS
CLK/HS
8
12 VDC
N/C
9
TXD
RXD
B.2 RS-232
RS-232 is used for asynchronous serial communication. It is a standard
EIA/TIA-232 DB9 socket female DCE interface. A DB9 male to male null
modem cable (pn 18663) is used to connect the AL200 to a Campbell
Scientific datalogger’s RS-232 port.
TABLE B-2. RS-232 Pin Description
Pin AL200 Function, DCE, DB9 Female
1
N/C
2
TXD
3
RXD
4
N/C
5
SIGNAL GND
6
N/C
7
CTS
8
RTS
9
N/C
