Model 109 Temperature Probe

7.2 Datalogger Programming

Short Cut is the best source for up-to-date datalogger programming code.

Programming code is needed when:

Creating a program for a new datalogger installation

Adding sensors to an existing datalogger program

If your data acquisition requirements are simple, you can probably create and

maintain a datalogger program exclusively with Short Cut. If your data

acquisition needs are more complex, the files that Short Cut creates are a great

source for programming code to start a new program or add to an existing

custom program.

Short Cut cannot edit programs after they are imported and edited

in CRBasic Editor.

A Short Cut tutorial is available in Section 4, Quickstart. If you wish to import

Short Cut code into CRBasic Editor to create or add to a customized program,

follow the procedure in Appendix A.1, Importing Short Cut Code into CRBasic

Editor. Programming basics are provided in the following section. A complete

program example can be found in Appendix B, Example Programs.

If the 109 probe is to be used with long cable lengths or in electrically noisy

environments, consider employing the measurement programming techniques

outlined in Section 8.3, Electrically Noisy Environments, and Section 8.4, Long

Cable Lengths.

Details of 109 probe measurement and linearization of the thermistor output

are provided in Section 8.2, Measurement and Output Linearization.

7.2.1 Therm109() Instruction

The

Therm109() measurement instruction programs most CRBasic

dataloggers (CR6-, CR200(X)-, and CR800-series, CR1000, CR3000, and

CR5000) to measure the 109 probe. It supplies 2500 mV excitation, makes a

half-bridge resistance measurement, and converts the result to temperature

using the Steinhart-Hart equation. See Section 8.2, Measurement and Output

Linearization, for more information.

Therm109() instruction and parameters

are as follows:

Therm109

(Dest, Reps, SEChan, VxChan, SettlingTime, Integ/Fnotch,

Mult, Offset)

The instruction for CR200(X) series dataloggers excludes the SettlingTime and

Integ parameters.

Variations:

Temperature reported as °C — set Mult to 1 and Offset to 0

Temperature reported as °F — set Mult to 1.8 and Offset to 32

Ac mains noise filtering — set Integ/Fnotch to _60Hz or _50Hz (see

Section 8.3, Electrically Noisy Environments)

Compensate for long cable lengths — Set SettlingTime to 20000

(see

Section 8.4, Long Cable Lengths)

NOTE
