Flytec 6010/6005 - Manual (Page 15)

14
Operating Instructions Flytec 6005/6010
Sink Alarm, Speed and Temperature
The 6005/10 has a sink alarm that will alert the pilot if he/she is descending faster than a
predetermined threshold; an airspeed display with a stall alarm that will alert the pilot if
their airspeed falls below a predetermined threshold and a temperature display.
Overview
Key Direct
Functions
Set.Mode Option-Mode
1 2 3 4 5 6
Sink Alarm
Audio On/Off
Audio
Sink alarm
threshold
ST
Unit
TEMP
°C, °F
Corr
Temp
Sensor
-8.0 to
+7.9
Unit
Speed
km/h, kts,
mph
Stall
Stall-
speed
Corr
SPEED
speed
corretion
+/- 50%
SPEED
diSP
change
speed /
temp
display
Sink alarm
Press the Sink Alarm Key to switch the Sink Alarm ON or
OFF The Sink Alarm icon will appear on the display when the
Sink Alarm is ON .
Set-Mode Sink Alarm
Press the Sink Alarm Key for three seconds to brings the
instrument into Sink Alarm Set-Mode. Use the Arrow Keys to
adjust the Sink Alarm Threshold between 40 and 2,000
ft/min.
Temperature Display
Without a speed sensor plugged into the 6005/10, the temp/speed display will show
ambient temperature. If a speed sensor is connected, then the display will alternate
between temperature and speed according to the interval set in the Option-Mode for the
Sink Alarm Key (option 6). Note: The temperature reading is delayed when there is a
rapid change in temperature since the temperature sensor is inside the housing.
Short
key
Key
3 sec
Key
3 sec
Short press
Short press
