Matrix Orbital VFD2041 Legacy - Manual (Page 30)

Table 20: Electrical Specifications
Supply Voltage 4.75 - 5.25 Vdc (optional 8 - 15 VDC)
Supply Current 11 mA typical
Table 21: Optical Characteristics
Number of Characters 80 (20 characters by 4 lines)
Matrix format 5 x 7 with underline
Display Area 76.3 x 25.20 mm XxY
Character Size 2.95 x 4.75 mm (XxY), not including underline
Character Pitch 3.55 mm
Line pitch 5.35 mm
Dot Size 0.55 x 0.55 mm (XxY)
Dot Pitch 0.60 x 0.60 mm (XxY)
Color of Illumination Yellow Green
WARNINGS
• Heavy shock of more then 100G, thermal shock greater then 10 ◦ C
/ minute, direct hit with a hard material to the glass surface (espe-
cially to the exhaust pipe) may CRACK the glass.
• Steady repeating of a static message displaying, longer than 5
hours in a day may cause a phosphor burnout problem.
Matrix Orbital VFD2041 27
