Matrix Orbital VFD2041 Legacy - Manual (Page 27)

Command Syntax Default Notes
Underline cursor on FE 4A
254 74
254 ’J’
off Turns on the un-
derline cursor.
Underline cursor off FE 4B
254 75
254 ’K’
Turns off the un-
derline cursor.
Block cursor on FE 53
254 83
254 ’S’
off Turns on the
blinking block
cursor.
Block cursor off FE 54
254 84
254 ’T’
Turns off the
blinking block
cursor
Cursor left FE 4C
254 76
254 ’L’
n/a Moves the cur-
sor one position
to the left. If the
cursor is already
at the beginning
of a line it will
move to the end
of the other line.
Cursor right FE 4D
254 77
254 ’M’
n/a Moves the cur-
sor one position
to the right. If the
cursor is already
at the end of a line
it will move to the
beginning of the
other line.
6.5 Bar Graphs and Special Characters
The commands in this section are used to define and display bar graphs and special characters.
Table 15: Bar Graphs and Special Characters
Command Syntax Notes
Initialize thick vertical bar
graph
FE 76
254 118
254 ’v’
Initializes the user character set to
make wide vertical bar graphs.
Matrix Orbital VFD2041 24
