1 Getting Started
Figure 1: GLK24064-25-WB
The GLK24064-25 is an intelligent graphic LCD display designed to decrease development time by
providing an instant solution to any project. With the ability to communicate via serial RS-232/TTL and I 2 C
protocols, the versatile GLK24064-25 can be used with virtually any controller. The ease of use is further
enhanced by an intuitive command structure to allow display settings such as backlight brightness, contrast
and baud rate to be software controlled. Additionally, text and fonts may be uploaded to the display and
stored in the on board memory.
1.1 Display Options Available
The GLK24064-25 comes in a variety of colors including the standard yellow/green, the popular blue/white
and the crisp white/grey. Extended voltage, and temperature options are also available, to allow you to select
the display which will best fit your project needs.
Figure 2: GLK24064-25 Options
1.2 Accessories
NOTE Matrix Orbital provides all the interface accessories needed to get your display
up and running. You will find these accessories and others on our e-commerce website at
http://www.matrixorbital.com. To contact a sales associate see Section 15.6 on page 63 for
contact information.
