Using an appropriate flathead screwdriver, dial the Time
Period (white) knob to the desired position, then dial the
Multiplication (blue) knob to the desired position. For
example, you want your pump to be ON (dispensing) for 24
minutes, and then to be OFF (not dispensing) for 3 hours:
1. Set the top (ON) Time Period knob to the 6 - 60 min range,
then dial the top Multiplication knob t0 the number 4. 6 x 4
= 24 minutes.
2. Set the bottom (OFF) Time Period knob to the 1 - 10 hr
range, then dial the bottom Multiplication knob t0 the
number 3. 1 x 3 = 3 hours .
NOTE: For TPURP pumps. the Start Timer button and
Remote Start option (using the 9-pin female
D-connector located on the rear panel) are not
supported.
