Aalborg TPV - Manual (Page 11)

11
2. Unscrew the thumbscrew at the end of the occlusion
clamp lever until the lever is loose enough to move.
3. Move the occlusion clamp lever to release all pressure
from the occlusion clamp, opening the tubing channel.
4. Loosen the 2 black thumbscrews on the tubing separator,
until the separator is free.
5. Lift the separator straight away from the pump face and
set it aside.
6. To load the tubing, lay the tubing in the pump channel
around the pump head, turning the pump head by hand in
either direction, with both ends of the tubing on the
righthand side.
7. When the tubing is in place, reinstall the tubing separator,
with each end cupping the tubing.
8. Finger tighten the black thumbscrews on the tubing
separator until the separator fits snugly against the tubing .
Make sure the tubing is immobilized but not pinched.
9. Snap the occlusion clamp lever back into place and tighten
its thumbscrew until the occlusion clamp is appropriately
tight.
10. Hold the safety cover in place as you reinstall both
thumbscrews. Finger tighten the thumbscrews.
CAUTION:
NEVER RUN THE PUMP WITHOUT THE
SAFETY COVER IN PLACE.
