21
FIGURE 7: MUR3 TIMER CONTROLS
1 Start Timer button 4 Multiplication knob
2 Timer ON/OFF switch 5 Relay timer Mode switch
3 Time Period knob
 Single Shot Mode
1. Using an appropriate flathead screwdriver, dial the Time
Period (white) knob to the desired position, then dial the
Multiplication (blue) knob to the desired position.
2. To run once for the programmed time period, set the relay
timer MUR3 Mode switch to B.
3. Activate the timed program manually by pressing the
pump’s Start Timer button, or activate it remotely via the
9-pin connector on the pump’s rear panel.
1
2
3
4
5
